DOUBLE PLATE OSTEOTOMY 35º IZQ.

DOUBLE PLATE OSTEOTOMY 35º DER.

Double osteotomãa plate 25º left.

Double/Triple Blocked Plate Pelvic Osteotomy 25th Right

LEFT BLOCK PLATE Large flag with 5 distal holes.
Length 110mm
28mm head wide
13mm tail
Thickness 3.5/4.0 mm
60 kg dogs

Left flag blocked plate with 5 distal holes.
Length 92mm
24 mm head width
12 mm tail width
Thickness 3.5/4.0 mm

Left blocked plate 4 distal holes.
Length 80 mm
24 mm head width
12 mm tail width
Thickness 3.5/4.0 mm

Right Blocked Plate with 5 distal holes.
Length 110mm
28 mm head wide
13 mm tail width
Thickness 3.5/4.0 mm
60 kg dogs

Right flag blocked plate with 5 distal holes.
Length 92mm
24 mm head width
12 mm tail width
Thickness 3.5/4.0 mm

Right blocked plate 4 distal holes
Length 80 mm
24 mm head width
12 mm tail width
Thickness 3.5/4.0 mm

Right blocked plate 5 distal holes.
Length 92mm
24 mm head width
12 mm tail width
Thickness 3.5/4.0 mm

Blocked plate Cranotomy of the tibia with 5 tail holes 3.5mm screws.
Length 92mm
Head 18 mm
12 mm tail
Thickness 3.5/4.0 mm

Blocked plate Cranotomy of the tibia with 4 tail holes 3.5mm screws.
Length 79 mm
Head 18 mm
12 mm tail
Thickness 3.5/4.0 mm

Blocked plate Cranotomy of the tibia with 3 tail holes 3.5mm screws.
Length 67 mm
Head 18 mm
12 mm tail
Thickness 3.5/4.0 mm

Blocked low contact plate.
Length 59 mm
16 mm head width
10 mm tail width
Thickness 2.5/3.0 mm

Blocked low contact plate.
Length 66 mm
17 mm head width
11 mm tail width
Thickness 2.5/3.0 mm

Blocked low contact plate.
Length 48 mm
14 mm head width
Cola width 8 mm
Thickness 2.5/3.0 mm

PBTPLE-24 BLOCK PLATE COBRA Ø 2.4 mm screws

Blocked plate Cobra 2.0 mm screws.
Length 39 mm
10 mm head width
6.0 mm tail width
2.5 mm thickness

PANARTRODESIS PLATE EKNICTED Carpal screws Ø 3.5-2.7. 2.0 mm distal screw. Distance from carporadial bone to distal end of the 76mm plate. Total length 148mm
